UHF RFID Иӡәӡәо Аӡәӡәарҭа атег Аӡы зҭамло амаҭәа Атег

UHF RFID Иӡәӡәо Аӡәӡәарҭа атег Аӡы зҭамло амаҭәа Атег

Абарҭ RFID зыӡәӡәо атегқәа ӡы зҭамло, уи амаҭәеи аполиестери рыла иҟаҵоуп, насгьы RFID амаҭәеи аԥсмаӡақәеи рнапхгаразы иҟаҵоуп. Урҭ еиуеиԥшым аусуратә температурақәа рыдгылара рылшоит. Атегқәа еиуеиԥшым адиаметрқәа/ашәагаақәа рыла иҟоуп.

Аҷыдара:
* Аҳауа аԥхарра ҳаракы иачҳауеит
* Иҳараку аԥхьаратә диапазон
* Иҟоуп аалыҵ ду змоу аҭбаараҿы, иҭышәынтәалоу апроцесс аманы
* Аӡы зҭамло, ақәыӷәӷәара ацәымӷра, ашьақар ацәымӷра
* Иҷыдоу аштрих-код, SKU, Логотип кьыԥхьтәуп.

Ахархәара: Амаҭәа атег, Аӡәӡәарҭа анапхгара, Еиԥшу ахаҭара, Амаҭәа ахәаахәҭразы алогистикатә система.

UHF RFID Washable Laundry tag waterproof fabric Clothing Tag

Item	flexible, washable label for laundry, garment retails applications with the best cost efficiency.
Material	Packing Material: Washer Wrinkle Fabric PET Substrate: Etched Aluminum Antenna,
Dimension	3454mm, 31.7590.00mm*0.35mm, etc
RF protocol	ISO 18000-6C; EPC Class 1 Gen 2,
Operating frequency	UHF 860-960MHz, Passive RFID
Chip	Impinj Monza R6P,U7,U8 or as per customer requirement.
IC life	100,000 Programming cycles, 50 Years of data retention.
ESD Voltage Immunity	Max. 2000V, with Human being mode(HBM)
Read Range	3-10Meter, depend on reader and antenna
Environmental Requirement
Adhesive Application Temperature/ Humidity:	-10 to +40 Celsius Degree, 20% to 80% RH;
Operating Temperature:	-25 to 60 Celsius Degree, 20% to 80% RH;
Shelf Life	From the date of manufacture, 1 Year at -25 ±5 Celsius Degree, 50%±10 RH; unseal the vacuum bag and avoid direct sunlight exposure.
Handling Precautions	inlays with ink marks are bad ones. DO NOT USE. The position of the mark is shown below. Reject Mark size 4.00mm in the center of the label in black.
Applications	Apparel Tag, Laundry Management, Uniform identity, Logistic system for Retail of Garment.
Features:	* High temperature resistant * High-performance reading range * Available in high-yield volume with stable process * Waterproof, pressure resistance and alkali resistance * Custom bar code, SKU, Logo printable.
